JBL Cinema CPI2000 Processor for Select 5.1 and 7.1 Surround Sound Systems (2 RU)

AED10,322

100% Original JBL Cinema Product

Compare

10 People watching this product now!

The 2 RU Cinema Processor from JBL is designed to provide audio enhancement and volume control for surround sound systems in cinemas. It features DSP processing, room EQ tuning, volume control, and system fault detection and can be configured through a specially designed GUI software. There are four inputs including analog, digital, non-sync, and mono microphone. This processor also features 10 x 15-pin analog output connectors for passive, bi-amp, or tri-amp connection and a 25-pin analog output connector for connection with a third-party audio system. Its redundant output works together with the analog input and will bypass this CPi2000 system to directly output audio signals in case power failure occurs.

Features

Name: JBL Cinema CPI2000 Processor for Select 5.1 and 7.1 Surround Sound Systems (2 RU)
Brand: JBL Cinema
SKU: CPI2000
Availability: InStock

Analog and digital inputs accept audio signal from any cinema server

Non-sync input receives line-level stereo signal from a CD or DVD player for background music playback

Microphone input connects to an RTA microphone for calibration or a vocal microphone for voice broadcast

USB port for configuration file import/export

LAN port for GUI control and firmware updates

Analog output 1 connects to a secondary, passive sound system

Redundant output for connection to a backup sound system in the event of power failure

Analog output 2 connectors connect to the main system, with support for passive, bi-amp or tri-amp speaker configurations, up to 7.1 channels

Universal power input with redundant DC power input (back-up power supply available separately)

Large LCD display on front panel shows channel levels, IP address, volume, and more

Quick-access controls for source selection and system volume

1/3 octave GEQ for room tuning via GUI software

Built-in with a list of variable crossover presets to accept a wide range of cinema speakers and reduce tuning time

Built-in crossover converts up to 7.1-channel audio to passive, bi-amp, or tri-amp

Supports TMS communication, convenient for remote control

Specifications

Connectors	1 x 25-Pin Female, Balanced Digital Input 1 x 25-Pin Female, Balanced/Unbalanced Analog Input 1 x 3-Pin XLR Female, Balanced/Unbalanced Microphone Input 1 x RCA L/R Non-Sync, Stereo Music Input 1 x 25-Pin Male, Balanced/Unbalanced Analog Output 1 x 25-Pin Male, Balanced/Unbalanced Redundant Output 10 x 15-Pin Female, Balanced/Unbalanced Analog Output 1 x USB Type-A, Port 1 x RJ45, LAN Port 1 x IEC, 100-240 V Power Input 1 x 4-Pin XLR Female, Backup 12 VDC, 2 A Power Input
Impedance	Digital Input: 110 Ohms Analog Input: 50 Kilohms Balanced, 25 Kilohms Unbalanced Microphone Input: 660 Ohms Non-Sync Music Input: 25 Kilohms Analog/Redundant Output: 30 Ohms
Input Level	Digital Input: 0.5 – 10 Vpp Analog Input: 14.2 dBu Max. Non-Sync Music Input & Analog/Redundant Output: 14.2 dBu
Total Gain	Microphone Input: 40 dB
Mic Input Noise (E.I.N.)	> 113 dB, 20 kHz Bandwidth
Frequency Response	20 Hz to 20 kHz, Ref 1 kHz ±1 dB
THD + N	< 0.01%, 20 Hz to 20 kHz
Dynamic Range	> 102 dB
Power	AC Input: 100-240 VAC, 50/60 Hz DC Input: 12 VDC, 2 A
Rack Space	2 RU
Dimensions	18.98 x 3.46 x 9.09″ / 482 x 88 x 231 mm
Weight	8.82 lb / 4 kg
